Post Processing
Form Wash & Form Cure
The Perfect Finish, Every Time
Produce parts you’ll be proud to deliver with a tried and tested, start-to-finish dental 3D printing workflow that’s certified biocompatible. Our post-processing solutions simplify and automate post-processing so you can consistently produce quality results and maintain a tidy workspace with less time and effort.
1. Print
Print your parts in just a few clicks with Formlabs 3D printers.
2. Wash
Insert the build platform directly into Form Wash after printing for a consistent, automatic rinse.
3. Cure
Transfer the part to our automated post-curing station, Form Cure, and cure using our recommended settings.
4. Done!
Parts are ready to deliver.
An Automated, Thorough Rinse
Form Wash agitates isopropyl alcohol (IPA) to perfectly clean your parts, then raises them to air dry once finished. Simply set the appropriate time and let Form Wash get to work. Once washing completes, parts air dry and are ready when you are.
Post-Curing, Simplified
Our automated post-curing solution, Form Cure, includes custom settings that maximize material performance, ensure consistent dimensional accuracy, and meet biocompatibility requirements for each Formlabs material with just the push of a button.
Less Effort, Higher Throughput
Form Wash and Form Cure streamline your 3D printing process so you can consistently produce high-quality parts with less time and effort.
Form Wash and Form Cure Tech Specs
| FORM WASH | FORM WASH L | |||
|---|---|---|---|---|
| Printer Compatibility | Form 3+, Form 3B+, Form 3, Form 3B, Form 2 | Form 3L, Form 3BL, Form 3+, Form 3B+, Form 3, Form 3B, Form 2 | ||
| Dimensions | 26.2 x 29.3 x 34.0 cm 10.3 x 11.5 x 13.4 in Height when open: 64 cm (25.2 in) |
78.0 x 46.0 x 67.0 cm 30.7 x 18.1 x 26.4 in Height when open: 113 cm (44.5 in) |
||
| Weight | 6.7 kg 14.5 lbs |
56.7 kg (without solvent) 125lbs (without solvent) |
||
| Bucket Volume | 8.6 L | 37.9 L 10 US gal |
||
| Maximum Part Size | 14.5 × 14.5 × 17.5 cm 5.7 x 5.7 x 6.9 in |
33.5 x 20 x 30 cm 13.2 x 7.9 x 11.8 in |
||
| Suggested Operating Environment |
Suggested 18—28 °C Suggested 64—82 °F |
Suggested 18—28 °C Suggested 64—82 °F |
||
| Agitation Method | Magnetically coupled impeller | Magnetically coupled impeller | ||
| Included Accessories | a. Wash Bucket b. Wash Basket c. Hydrometer d. Siphon Pump e. Flexible Scraper f. Scraper g. Tweezers h. Flush Cutters |
a. Wash Bucket b. Wash Basket c. Electric Solvent Pump d. Flexible Scraper e. Scraper f. Flush Cutters g. Rinse Bottle h. Gloves i. Form 3 Build Platform Adaptor |
||
| Power Requirements | 90–240 V 2.0 A 50/60 Hz 50 W |
100–120 V (NA), 220 – 240 V (EU) 1.0 A 50/60 Hz (NA), 1.0 A 50/60 Hz (EU) |
||
| Compatible Solvents | IPA, TPM, Water | IPA, TPM, Water |
| FORM CURE | FORM CURE L | |||
|---|---|---|---|---|
| Printer Compatibility | Form 3+, Form 3B+, Form 3, Form 3B, Form 2 | Form 3L, Form 3BL, Form 3+, Form 3B+, Form 3, Form 3B, Form 2 | ||
| Dimensions | 26.2 x 26.2 x 34.0 cm 10.3 x 10.3 x 13.4 in Height when open: 64 cm (25.2 in) |
69.0 x 54.0 x 44.5 cm 27.2 x 21.3 x 17.5 in |
||
| Weight | 5.6 kg 12.4 lbs |
24kg 53 lb |
||
| Turntable Diameter | 19.3 cm 7.6 in |
39.5 cm 15.6 in |
||
| Maximum Part Height | 18.5 cm 7.28 in |
32 cm 12.6 in |
||
| Operating Temperature | Suggested 18—28 °C Suggested 64—82 °F |
Suggested 18—28 °C Suggested 64—82 °F |
||
| Maximum Cure Chamber | 80 °C 176 °F |
80 °C 176 °F |
||
| Light Source | 13 multi-directional LEDs | 45 multi-directional LEDs | ||
| LED Power | 39 W | 70W | ||
| LED Radiant | 9.1 W | 36W | ||
| LED Wavelength | 405 nm | 375 nm, 405nm | ||
| Power Requirements | 90–240 V 6.0 A 50/60 Hz 144 W |
100–120 V (NA), 220–240 V (EU) 15.0 A 50/60Hz (NA), 8.0 A 50/60Hz (EU) |
Details
| Brand | Form Labs |
| Model | Form Wash |
| Condition | New |
| Warranty | 12 Months |
| Shipping From | United Kingdom |
| Category | Post Processing Unit |
